For 18 years, “ACE Packaging Solutions“, A pallet stretch wrapping machine is a machine used to wrap stretch film around pallets or packages to secure them for transportation or storage. The machine typically consists of a turntable that the pallet or package sits on, a film carriage that holds the roll of film, and a stretch wrapping arm that rotates around the pallet or package applying the film in a continuous motion.

Automatic Stretch Wrapping Machine

Salient Features:

  • Flexible ramp location.
  • Modular in construction.
  • Fully Automatic operation machine.
  • Powered Pre-Stretch upto 300% Stretch.
  • Heavy duty turn table for all industry applications
  • The powered Pre-Stretch unit ensures stronger packing, While consuming the least quantity of film.

Applications:

Textile yarns like cotton, polyester, Jute etc.,Casting, canned foods, Bottel crates, fertilizers or gains in sacks & bags , pails & tins, Carton boxes, ceramic, item ,tiles and many more.

Layout : Classic

Diagram of Pattel Shrinking Machine

Specifications

Production speed 15-20 pallets/hour
Pallet Size1200x1200mm
Pallet Hieght2600mm
Max. weight/pallet2000kg

Machine

Turn table diameter

1500mm

Turn table Height

80mm

Turn table speed

1-10rpm

Max. powered Stretch

300%

Installed Power

1.5KW

Power Supply

220v/single phase/50hz

Film Details

Material

LLDPE Stretch Film

Film Width

250-500mm

Film thickness-range

12-35µ

Film thickness-Used

23µ

core diameter

76mm

Max. Film diameter

250mm
